| Manufacturer | Avolites |
|---|---|
| Hardware & Capacity | : |
| Playback Faders | 10 physical playbacks with assignable controls |
| Encoders | 3 precision metal-shaft optical encoder wheels |
| DMX Connectivity | 4 physical optically isolated 5-pin XLR connectors |
| Channel Capacity | 8,192 channels native (up to 16 universes via ArtNet/sACN), expandable to 64 universes using Titan Net Processors. Max system capacity of 32,768 channels |
| Power | USB powered (no external mains connection required) |
| Software & Control | : |
| Software | Powered by the Avolites Titan platform, compatible with show files from other Titan-based consoles |
| Effects & Mapping | Built-in Capture 3D visualization engine, keyframe effect engine, and animation/Synergy-based pixel mapping |
| External Control | MIDI support (Timecode and Notes), Web API, and sACN. Supports up to 2 external touchscreens |
| Physical Specs & Requirements | : |
| Dimensions | 4.9 kg |
| Minimum PC Requirements | Windows 10, Intel Core i5 2 GHz processor, 4GB–8GB RAM, and a GPU with Passmark 700 or higher |
