Do you need to hire conference equipment? Ideal for conferences, networking, presentations and business events – The PDS-4K SDI enables single screen, dual screen switching and quad screen switching. It has high-quality 4K processing, and it can also support Dante® audio with the addition of an optional interface card.
It includes:
The PDS-4K SDI switcher guarantees unsurpassed performances and outstanding visual experience while also being exceptionally easy to operate. With just one simple press on the buttons of the intuitive front panel interface, you can switch easily between the input sources and preconfigured layouts. What’s more, the PDS-4K SDI is compatible with all the familiar Barco visualization solutions and presentation devices (e.g. ClickShare) without compromising on video quality. The PDS-4K can be controlled with Event Master Toolset, but thanks to the API it can also be combined with other third- party control panels
The PDS-4K SDI is built for applications requiring the highest availability and uptime. The switcher also proves to be a smart investment well into the future with option cards to ensure expandability and future-proof upgradability.
If you are planning a conference, corporate or business event then get in touch with the team today: info@bigaboxproductions.co.uk. Or you can complete to form below!
| Manufacturer | Barco |
|---|---|
| Notes | Option Card slot to support additional video input connectors, embedded audio processing and Dante Audio |
| Live effects canvas | 2x outputs up to 4K60 or 4x outputs up to 4K30 each with a single mixing PiP or two non-mixing PiPs on a still background |
| Video inputs | 6x HDMI™ 2.0 connectors 2x 12G-SDI connectors |
| Video outputs | 4x HDMI™ 2.0 connectors 4x 12G-SDI connectors |
| Program output | Two UHD @60 PGM or Four UHD @30 / FHD @60 PGM |
| Keying/Mixing | Luma and Chroma on non-mixing PiPs |
| Mixers | 1 mixer per PGM output |
| Still stores | Eight stills, up to 4K each |
| Multiviewer | 1x UHD@60 output with user definable layouts consisting of inputs plus PVW and PGM for each screen |
| Expandability | Option card slot for other video connector types and/or Dante audio |
| HDCP | HDCP 1.x and 2.2 |
| Dimensions (HxWxD) | 6.62 cm (2.605 in) x 48.41 cm (19.06 in) x 40,9 cm (16.1 in) |
| Control | front panel mappable buttons Event Master screen management software for PC or MAC Event Master controllers WebUI Ethernet RJ-45, 1000/100/10 Mbps Autosense |
| Noise Level | 37 dB in a room temperature environment (23C/73F) |
| Weight | 6.21 kg (13.7 lbs) |
| Power | Input power: 100-240 CAV 50/60Hz 151W |
| Environmental Humidity | 0-95% non-condensing (non-operating) 0-85% non-condensing (operational) |
Our catalogue and dry hire capability includes everything from audio, lighting, LED video, and rigging and structures to set design, build and more. We supply both industry standard and market-leading event equipment and technologies to ensure that you receive the very best event production services possible at all times. Call or email us to find out more:
