Whether used for sports broadcasting, live concerts, or large-scale events, the HDC-3500/3500VÂ delivers stunning 4K resolution with remarkable detail, color accuracy, and dynamic range. Its versatility makes it an ideal choice for both studio and field applications.
| Manufacturer | Sony |
|---|---|
| Power | 240 V AC, 1.4 A (max.), 240 V DC, 1.05 A (max.) |
| Operating temperature | From 20°C to +45°C |
| Storage temperature | From 20°C to +60°C |
| Weight | Approximately 4.9 kg (unit only) Approximately 5.1 kg (with HKC-TR37) Approximately 4.9 kg (with HKC-FB30) |
| Frame | 2/3″ type 4K CMOS sensor with global shutter |
| Method | 3 CMOS sensors, RGB |
| Sensitivity | F10 with 1080/59.94p F11 with 1080/50p (at 2000 lux with 89.9% reflection) |
| Signal-to-noise ratio | -62 dB |
| Geometric distortion | Insignificant (excluding distortion due to the lens) |
| Spectral system | Prism F1.4 |
| Built-in filters | Neutral Density Filters: 1: Clear, 2: 1/4ND, 3: 1/8ND, 4: 1/16ND, 5: 1/64ND Color Correction Filters: A: Cross filter, B: 3200K (transparent), C: 4300K, D: 6300K |
| CCU | Electro-optical connector (LEMO 3K.93C connector) (x1) |
| LENS (Objective) | 12 pins (x1) |
| Viewfinder | 20 pins (x1) |
| 1 MIC input | 3-pin XLR, female (x 1) |
| Audio input CH1, CH2 | 3-pin XLR, female (one each) Audio selection on MIC: -60 dBu (selectable down to -20 dBu in the menu), balanced Audio selection on LINE: 0 dBu, balanced |
| INTERCOM 1, INTERCOM 2 | XLR 5-pin, female (x1 each) |
| EARPHONE (headset) | 4-pole mini-jack (x1) (mono 2-pole, stereo 3-pole, CTIA standard 4-pole, OMTP standard 4-pole) |
| CC ENTRANCE | 4-pin XLR (x1), 10.5 to 17 V DC |
| DC OUT | 4 pins (x1), from 10.5 to 17 V DC, 0.5 A*1 max., 2 pins (x1), from 10.5 to 17 V DC, 2.5 A*1 max. |
| SDI 1 | BNC (x1 |
| SDI 2 | BNC (x1) |
| SDI-MONI | BNC (x1) |
| TEST OUT | BNC (x1) |
| PROMPTER/GENLOCK | BNC (x1) PROMPTER 1 Vp-p, 75 Ω GENLOCK HD: SMPTE ST274, sync. triple level, 0.6 Vp-p, 75 Ω, SD: Black burst (NTSC: 0.286 Vp-p, 75 Ω / PAL: 0.3 Vp-p, 75 Ω) |
| PROMPTOR 2 | BNC (x 1), 1 V DC, 75 Ω |
| RET CTRL | 6 pins (x1) |
| REMOTE | 8 pins (x 1) |
| TRACKER | 12 pins (x1) |
| CRANE | 12 pins (x1) |
| USB | USB 2.0 type A, 4-pin (x1) (for connecting a USB drive) |
| MAIN NETWORK LINE | RJ-45 8-pin (x1) |
