Y10P Loudspeaker

This speaker is the ideal kit for live performance venues, concerts and tours, theatre, musical productions and live events. The compact, 2-way passive Y10P loudspeaker features two 8” drivers in a dipole arrangement with a 1.4” compression driver mounted onto a rotatable CD horn. Sophisticated horn geometry combined with the advanced bass-reflex port design delivers full bandwidth capabilities with an extended LF output. These point source, high-performance cabinets offer 110° horizontal directivity controlled down to 500 Hz, matched with a vertical dispersion of 40°. The horn can be rotated by 90° to enable horizontal orientation. The Y10P provides a broad variety of deployment possibilities, especially when used as a stand-alone full-range system, or combined with other elements from the Y-Series, either ground stacked or flown. The loudspeaker cabinet is constructed from marine plywood and has an impact and weather-protected PCP (Polyurea Cabinet Protection) finish. The front of the loudspeaker cabinet is protected by a rigid metal grill backed by an acoustically transparent foam. The cabinet incorporates a pair of handles whilst M10 threaded inserts are provided for attaching d&b rigging hardware. Additionally, two further M10 sockets accept the 8mm load pin to expand the mounting options.

We provide the very best audio equipment available, to event production professionals, tour managers, agencies and businesses. If you are looking for Audio Equipment for your next event, this speaker is the ideal kit for live performance venues, corporate events, concerts and tours, theatre, musical productions and live events and it is perfect for Live Events no matter the size. Loudspeakers, also known as transducers or drivers and they can come in various sizes and styles. Their purpose is to turn electrical audio signals into acoustical sound waves that we can hear. The most common design type is the moving coil loudspeaker. It uses a permanent magnet, a voice coil, and a cone. With the epitome of line array loudspeakers and a new generation of point sources, the Y-Series range is all-encompassing.

Hire Audio Equipment for Events

Point sources – High performance 2-way passive point source loudspeaker.

  • Components 2 x 8″/1.4″
  • Dispersion 110° x 40°
  • SPLmax 136 dB
  • Weight 18 kg / 40 lb

System data

  • Frequency response (-5 dB standard) – 59 Hz – 18 kHz
  • Frequency response (-5 dB CUT mode) – 118 Hz – 18 kHz
  • Max. sound pressure1 – with 10D – 131 dB
  • with D20/30D – 134 dB
  • with D40/D80/40D – 136 dB
  • Cabinets per amplifier channel – 2

Loudspeaker data

  • Configuration: High performance 2-way passive point source loudspeaker
  • Nominal impedance: 8 Ω
  • Power handling capacity (RMS/peak 10 ms): 400/1600 W
  • Nominal dispersion angle (h x v): 110° x 40°
  • Components: 2 x 8″ driver with neodymium magnet
  • 1.4″ exit compression driver: passive crossover network
  • Connections: 2 x NLT4 F/M
  • Optional 2 x NL4 or 2 x EP5

If you are not sure what sound system you need for your event, complete the form below and someone will be in touch.

Audio for Events, Sound System, Live Events, Conferences

ManufacturerD&B
